Drum Roaster – 100L

169,000499,000

Around the globe, the focus is on the use of renewable energies. In order to save natural resources and protect our environment, many master roasters are also very interested in operating their coffee roasting machines with an electric heating system. Easy to operate and without compromising the exact sequence of the given roasting curve.

Product Variation

Feature

Capabilities: Roasting, Coating, Drying, and Mixing can be effortlessly accomplished.
High Efficiency Uniform Air Roasting: Designed for optimal efficiency, providing precise air temperature ensures each nut, spice,
or grain is uniformly roasted for consistent quality.
Ceramic Heating Elements: Utilizes ceramic heating elements to generate temperatures of 450–900 °C for optimal roasting.
PID Controller: Equipped with a PID controller for precise temperature and airflow control.
Drum Tilting System: The inclusion of a drum tilting system facilitates the seamless discharge of materials from the laden drum subsequent to the roasting process.
Reverse Drum Rotation: Allows easy draining of materials without the need for manual intervention

use case

technical specifications

Drum Volume 100L
Roasting Capacity – High Bulk Density [Eg. Almonds] 25 [KG per batch]
Roasting Capacity – High Bulk Density [Eg. Makhana] 6 [KG per batch]
Drum Material Food-Grade Stainless Steel
Structure Material Mild Steel
Heating Source Electric Heater
Temperature Range 0-400°C
Jacketed Drum Jacketed drum in the Raptor Series
Drum Rotation Speed adjustable with variable control, enabling consistent and even roasting of different product varieties and roast profiles.
Control System Manual
Air Circulation System High-efficiency blower for uniform heat distribution
Cooling System Integrated cooling system with blower
Heat Insulation High-grade thermal insulation with a jacketed drum to minimize heat loss
Power Consumption 6kWh
Power Supply 415VAc | 50hz | 3 Phase
Machine Dimensions Width: [ ] mm, Depth: [ ] mm, Height: [ ] mm
Machine Weight 150Kgs Approx
